224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯火力发电用汽车发思想然油区域可靠性好: 现进的然油掌控模式，独特的STC、ESTC 分级制度掌控模式，比较特殊设计构思的活塞式表层点燃室，直流电喷涌然油，足够吸雾，点燃足够。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯生产发电用打火机瞬态安全性能优异的: 完美无缺的打火机整体性规划，紧密配合康明斯独家的EFC装置，保持精确高，响应的时间段快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯带发电用起动因升工作功率高: 一体化设汁狭窄.形态摆置合理安排，启动保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷手机型号 QSNT. QSK19. QSK38. QSK50足够我国非通道第三方阶段中及北美洲Tier2. Tier 3排卸政策法规规范。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件可获性好， 起思想开机运行及维系保養快捷，人工低成本。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

功效标准 Power Range   224-310KW结构类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观形状图片尺寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效率 Dry Weight   940kg

224-310KW康明斯带发电用发起机的优点和缺点：占地小， 缩减比低， 格栅板氧气烧水，适于初始化，电信车载导航供电的都喜欢选用。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

起心理具体型号	选用输出功率(kW)Prime Power	后备电源公率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
